Desktop silicone auto dispensing machine SPL-D5331-3
Description
Parameter configuration
| Model | SPL-D5331-3 |
| Work schedule | 500/300/300/100/360 (mm) customizable |
| Programming method | Teach programming or graphic import |
| Glue dispensing amount | 0.01ml |
| Glue dispensing frequency | 5 seconds/time |
| Glue bucket | 2600ML |
| Movement speed | 300-800mm/s (customizable) |
| Repeatability accuracy | ±0.02mm |
| Program recording method | 100 sets |
| Display mode | LED teaching box |
| Transmission method | Synchronous belt/screw+guide rail |
| Dispensing valve | Precision suction valve (optional according to product) |
| Input power | AC220V |
| Overall dimensions | 720*623*600(mm) |
Main Features:
- Adopting high-precision dispensing control technology
- Specially designed for silicone and other adhesives with poor fluidity and high viscosity
- Capable of achieving precise dispensing at any position within the space
- Can accurately control the amount of glue produced through the suction valve
- Stable dispensing volume, no leakage or dripping of glue, ensuring consistency and reliability of dispensing
