Synchronous belt linear module DT45
Описание
Parameter configuration
| Spec | Repeatability(mm) | ±0.01 | ||||
| Ball Screw Lead(mm) | 5 | 10 | 16 | 32 | ||
| Max imum Speed(mm/s) | 250 | 500 | 800 | 1600 | ||
| Maximum Payload | Horizontal(kg) | 50 | 30 | 18 | 5 | |
| Vertical(kg) | 15 | 8 | 3 | — | ||
| Rate Thrust(N） | 341 | 170 | 85 | 53 | ||
| Stroke Pitch(mm) | 100~1000mm/50mm pitch | |||||
| Parts | AC Servo Motor Output(W) | 200 | ||||
| Ball Screwø(mm) | C7ø16 | |||||
| Linear Guide(mm) | 15×12.5 | |||||
| Couping(mm) | 10×14 | |||||
| Home Sensor | Outside | EE-SX672(NPN) | ||||
| Built in | EE-SX674(NPN) | |||||
Main Features:
- The maximum travel distance is up to 1000MM
- Adopting a semi enclosed structure with double guide rails and double sliders
- Stable performance and strong universality
- General environmental use
- *Note: For specific specifications and models, please contact our business personnel for consultation.
